4020 Single Table Laser Cutting Machine
Key Features
Compact design for small workshops
Energy-efficient fiber laser source
User-friendly touchscreen interface
Capable of cutting carbon steel, stainless steel, aluminum, brass
Main Configuration
| Laser source | Raycus Fiber Laser |
| Laser head | Boci/Precitec |
| Control system | Cypcut System |
| Water chiller | Tongfei |
| Servo motor | Yaskawa |
| Reducer | Shimpo/Motovario |
| Guide | HiWin |
| Gear&Rack | YYC |
| Air conditioner | KW |
| Valve | SMC |
Technical Specifications
| laser_power | 3kW-12kW |
| cutting_area | 4000x2000mm |
| max_thickness | 30mm carbon steel |
| positioning_speed | 100m/min |
| repeatability | ±0.05mm |
| acceleration | 1.2G |
Cutting Samples
